OXZAWhy aspect ratio matters more than size
Most riders shop by size. Size is the wrong first question.
Walk into any foil conversation and the first number traded is area: "I'm on a 1000", "I dropped to an 800". Area is real — it sets how early you lift and roughly how slow you can fly — but it says nothing about how the wing flies once it's up. That is the job of aspect ratio.
Aspect ratio = span² ÷ area. A wing with 900 mm of span and 800 cm² of area has an AR of about 10. Stretch the same 800 cm² across 1,000 mm and AR climbs to 12.5. Squash it into 750 mm and it drops to 7.
What aspect ratio changes
| Trait | Low AR (≈ 6–8) | Mid AR (≈ 8–10) | High AR (≈ 10–13+) |
|---|---|---|---|
| Lift onset | Early, at low speed | Balanced | Later, needs speed |
| Glide / efficiency | Modest | Good | Exceptional |
| Pump | Short, forgiving | Wide window | Long, efficient, technique-dependent |
| Turning | Loose, tight radius | Carvy | Drawn-out arcs |
| Stall behaviour | Soft, progressive | Predictable | Sudden if you drop below the window |
| Typical use | First foils, surf, light wind | Daily driver, progression | Downwind, race, high-wind glide |
A high-aspect planform spreads lift across a long, thin span. Induced drag — the drag that comes from making lift — falls as span grows, so the wing converts every pump and every gust into forward run. The cost is a narrower speed window: drop below it and the wing lets go with little warning.
A low-aspect planform stacks lift deep in the chord. It tolerates bad angles, lifts early, and turns on a dime. The cost is drag: it will not glide through a lull the way a high-AR wing will.
Two REVSTAR wings, same ballpark area, different sports
- REVSTAR-A 800 — 901 mm span, AR 8.25. Added lift and glide, shrugs off bad technique and keeps flying.
- REVSTAR-L 750 — 999 mm span, AR 13. Maximum glide and efficiency; every pump becomes forward run.
The L will out-glide the A in every lull. The A will save you in every botched touchdown. Neither is "better" — they are built for different riders, which is exactly why OXZA ships five ride families instead of one long list of sizes.
How to read the REVSTAR range
The family letter is a ramp in aspect ratio as much as a ramp in intent:
| Family | Typical AR | Feel |
|---|---|---|
| A — Allround | 7–9 | Confidence, range, progression |
| C — Carve / Control | 8.6–12 | Sharper turns, control, efficiency |
| L — Lift / Glide | 11.5–13 | Easy lift, low-speed glide |
| R — Race / Performance | 10.7–11.4 | Faster profiles, reduced drag |
| S — Speed Halo | In iteration | Maximum top-end speed |
The ramp from A to S is also a ramp in how much precision the wing demands from you. Move up it when your technique has headroom, not because a bigger number sounds faster.
A practical rule
- Pick the family for how you want to ride in a year, not today.
- Pick the aspect ratio inside that family for the conditions you actually get.
- Pick the size last, by body weight and wind range.
Then let Build Your Setup pair it with a mast, fuselage and stabilizer that are already known to work together.
Questions
What is aspect ratio on a foil wing?
Aspect ratio (AR) is span squared divided by projected area. A high-AR wing is long and narrow; a low-AR wing is short and deep. Same area, very different ride.
Is a higher aspect ratio foil better?
Not better — different. High AR gives more glide, efficiency and pump range but demands cleaner technique and a narrower speed window. Low AR is forgiving, turny and lifts early at low speed.
What aspect ratio should a beginner wing foiler choose?
Most riders progress fastest on a mid-aspect wing around AR 7–9. In the REVSTAR range that is the A family — for example the REVSTAR-A 725s at AR 8.25.
